Remove safely iron and manganese from water with Watercel ZF
Watercel ZF acts directly to remove soluble (Fe2+ and Mn2+) and particulate (Fe3+ and Mn4+) iron and manganese present in water.
- Particle size: 0.4 to 1.0 mm
- Uniformity coefficient: 1 to 1.9
- Apparent density: 0.9 – 1.0 g/cm³
- pH: 2.5-5.0
- Color: Brown
- Moisture content: ≤ 12%
- Melting point: 1000 – 1400 °C
Safe product. Safety tested according to GM/MS Standard No. 888/21, based on NSF/ANSI Standard 61 (2016).
Increased water production due to high filtration rates.
Reduced backwash water consumption due to low backwash requirements.
Lower pressure drop due to high porosity, which promotes greater water production capacity.
High iron and manganese adsorption capacity using lower quantities of product per cubic meter of water treated.
Recommended use
| Filtration rate | 10 to 30 m³/m².h |
| Backwash rate | 25 to 35 m³/m²·h |
| Filter expansion | 20 to 30% |
| pH | 6.0 to 8.5 (6 to 7.5 up to 2 ppm of Mn.For values above this, use a pH between 8.0 and 8.5). Work with a pH of 7.5 for iron ≥ 4.0 ppm. |
| Apparent density | 0,98 kg/L (g/cm³) |
| Bed support | Use only 1/8 to 1/16 gravel (minimum height of 200 mm)or use Zeomedia 4-6 and 1/8 to 1/16 gravel (minimum height of 100 mm for each particle size) |
| Maximum concentrations | ≤ 11,0 mg/L iron.≤ 6,0 mg/L manganese |
| Maximum permissible turbidity at the filter inlet | ≤ 10 NTU |
| Outlet free chlorine | 1,0 to 2,0 mg/L |
Casos de éxito
CFE “Plutarco Elías Calles” Thermoelectric Power Plant
Zeomedia’s first full-scale industrial project. 0.7 NTU effluent: the plant eliminated coagulation and flocculation prior to reverse osmosis Filtration runs doubled; backwash water consumption reduced by 50% OPEX 6.1× lower than silica sand; tanks 29% more compact and without air
Zeomedia guarantee promise
We identify ways your system can be optimized and show you different high-performance options so you can save on your daily operations. Written guarantee.
Frequently Asked Questions
How can I be sure of the savings and benefits of filtration engineering?
We perform calculations and simulations to ensure accurate forecasts. We also have extensive experience with various client success stories that have been satisfied thanks to our technical support.
How can I be sure it works specifically for my system, since my water treatment is very complex?
We know that every project is different and each one incorporates specific variables. Contact us for a technical consultation.
What is the Zeomedia guarantee?
If the projected savings aren’t achieved, we’ll either provide the savings or refund your investment. Visit our dedicated section for terms and conditions.
